PCBMay: Your Trusted Medical PCB Manufacturing & Assembly Supplier
PCBMay is committed to providing reliable and precision PCB manufacturing and assembly services to medical device customers worldwide.
PCBMay is committed to providing reliable and precision PCB manufacturing and assembly services to medical device customers worldwide.
PCBMay is a leading manufacturer specializing in medical-grade PCB production and assembly. With over 20 years of industry experience, we are committed to providing global medical device OEMs with one-stop technical solutions. From high-precision custom PCB production, component sourcing to precision PCBA assembly.
PCB Fabrication Center: 13,000 sq m facility with a monthly capacity of 40,000 sq.m, powered by fully automated production lines.
PCBA Assembly Center: 8,000 sq m workshop featuring 8 high-speed SMT lines, 2 wave soldering lines, and 5 dedicated assembly lines.
Auxerunt haec vulgi sordidioris a udaciam ob haec festinatis.
Auxerunt haec vulgi sordidioris a udaciam ob haec festinatis.
Auxerunt haec vulgi sordidioris a udaciam ob haec festinatis.
We expertise in processing a wide range of substrates, including Rigid-Flex, Rogers (High-Frequency), and Polyimide (Flex). We ensure superior thermal management and signal integrity for critical medical imaging and monitoring systems.
We specialize in Any-layer HDI and microvia technology up to 40 layers. We achieve ultra-fine 3/3 mil trace/space to meet the miniaturization requirements of implantable devices and handheld diagnostic tools.
Our factory is equipped with 8 high-speed automated SMT lines capable of handling 01005 components and ultra-fine pitch BGA/QFN. Our precision placement ensures the reliability of complex medical control boards and wearable health sensors.
Our facility delivers robust production power with an SMT capacity of 3M–4M soldering pads/day and a DIP capacity of 100K pins/day. This scalability allows us to maintain stable lead times and rapid response for both urgent NPI prototypes and high-volume medical device orders.
Nisi mihi Phaedrum, inquam, tu mentitum aut Zenonem putas, quorum utrumque audivi, cum mihi nihil sane praeter sedulitatem probarent, omnes mihi Epicuri sententiae satis notae sunt. atque eos, quos nominavi, cum Attico nostro frequenter audivi
We use high-speed 3D AOI systems to detect component misplacements, solder bridge issues, and polarity errors. This ensures 100% surface-level accuracy for even the most densely populated medical PCBA.
We use X-ray inspection for BGA, QFN, and multi-layer PCB designs. Our X-ray inspection detects hidden solder voids and internal layer misalignments, guaranteeing the structural integrity of complex medical circuits.
We perform comprehensive ICT to verify component values and electrical connectivity. This stage identifies manufacturing defects such as opens, shorts, and incorrect components before final assembly.
We provide custom test fixtures and corresponding testing services per your project’s test plan.
PCBMay is a PCB manufacturing and assembly supplier specializing in medical devices, backed by a comprehensive certification system. We hold ISO 9001:2015, ISO 14001:2015, UL, and RoHS certifications. These certifications demonstrate our commitment to quality, safety, and compliance, meeting global market access standards. It also serves as the key foundation for ensuring the reliable manufacturing and assembly of your medical devices.
Per hoc minui studium suum existimans Paulus, ut erat in conplicandis negotiis artifex dirus, unde ei Catenae inditum est cognomentum
